產品參數
輸入電壓:AC110v - 240 v / 50-60HZ
光源規格400W
光源壽命:20000小時
流明照度: 5米120000 lm 額定功率:430 w 通道模式:23ch
水平掃描:540度(16位精密掃描)電子糾錯
垂直掃描:270度(16位精密掃描)電子糾錯
調光系統:0-100%線性調節
聚焦系統: 從4米到50米線性調節
霧化系統: 1個獨立霧化效果，光斑柔和自然
放大角度: 4-35度
高速頻閃: 0-30次/秒。調速頻閃效果可調。斯特羅布宏函數
顏色:8色+白光,半色功能
調色系統:線性CMY+CTO調色系統。
固定模式:12個固定模式+白光
旋轉圖案:7個玻璃圖案，每個玻璃圖案可獨立正反轉
棱鏡系統:標準單六排棱鏡和8棱鏡，每個棱鏡可獨立正反向
宏功能:控制臺復位功能、自走模式、主從模式
顯示方式:液晶顯示，按鍵+觸摸雙操作模式
控制信號:國際標準DMX512。具有RDM功能，可進行軟件在線升級，
撥打地址碼
冷卻方式:采用軸流風機加強冷卻
安全裝置:設有電子溫控過熱保護，當過熱系統失效時，電子溫控自
動斷電保護
外觀材料:耐高溫塑料
工作環境:-20度- 40度
保護級別:IP20
產品凈重:22.5KG
產品尺寸:38*27*65CM (L*W*H)
Input voltage: AC110v - 240v/50-60HZ
Light source specification 400W
Light source life: 20000 hours
Luminous illumination: 5 meters 120000 lm
Rated power: 430 w
Channel mode: 23ch
Horizontal scanning: 540 degrees (16 bit precision scanning) electronic error correction
Vertical scanning: 270 degrees (16 bit precision scanning) electronic error correction
Dimming system: 0-100% linear adjustment
Focusing system: linear adjustment from 4m to 50m
Atomization system: 1 independent atomization effect, soft and natural light spot
Enlargement angle: 4-35 degrees
High speed strobe: 0-30 times/second. Adjustable speed strobe effect. Strobe macro function
Color: 8 colors+white light, half color function
Color mixing system: Linear CMY+CTO color mixing system.
Fixed mode: 12 fixed modes+white light
Rotating pattern: 7 glass patterns, each glass pattern can be independently reversed
Prism system: standard single six-row prism and 8-prism, each prism can be independently forward and backward
Macro functions: console reset function, self-propelled mode, master-slave mode
Display mode: LCD display, button+touch dual operation mode
Control signal: international standard DMX512. With RDM function, software can be upgraded online and address code can be dialed
Cooling method: use axial flow fan to enhance cooling
Safety device: equipped with electronic temperature control overheat protection. When the overheat system fails, the electronic temperature control automatically powers off for protection
Appearance material: high-temperature resistant plastic
Working environment: - 20 degrees to 40 degrees
Protection level: Ip20
Net weight of product: 22.5KG
Product size: 38 * 27 * 65CM (L * W * H)
