產品參數
XL-CZ3110
1.額定電壓：AC110V～240V,50～60Hz
2.功率:350W
3.光源：31顆10W CREE燈珠/平均壽命：50000H
4.色溫校正：3200K～5600K線性調節
5.透鏡角度：25°（可選）
6.發光角度：可手動調節角度
7.頻閃：獨立電子頻閃1-25Hz，可隨機頻閃，脈沖頻閃，同步異步頻閃，單色、混色溫頻閃
8.混色：單色無，雙色WY混色（0-100%飽和度可調），內置宏功能
9.電子調光：0-100%獨立電子線性調光，攝像視頻真實無閃爍，主從自走自動同步功能，控臺正常控制自走永久同步
10.液晶顯示菜單：調用各種場景，內置程序可以直接調用執行
11.控制模式：多種聲控、DMX512、主從聯機模式
12.通道：2通道
13.燈具連接：三芯信號線IN/OUT 電源線IN/OUT
14.特點：鑄鋁外殼，光效高，混光均勻，性能穩定，配一進一出手拉手1.5米長電源、信號線，1024級超高灰度調光更加柔和，
15.防護等級：電氣Ⅱ級，防火V-1，防護IP33
16.聲控靈敏度：65-130dB
17.工作環境：-20℃~40℃
⊙采用高顯色指數進口LED作為發光元件，滿足專業攝影、攝像要求。
⊙LED光源為固體發光器件，壽命長達50000小時，是新一代綠色環保光源。
⊙高功率密度的LED模組和高效的非球面聚光系統，燈具光效高、光束角大、光斑均勻，比傳統燈管節能90%。
⊙內置DMX512信號控制，亮度調節范圍0~100%，旋鈕調節，和調光臺調節亮度，無需硅箱。
Rated voltage: AC110V~240V, 50~60Hz
Power: 200W
Light source: 31 10W CREE SMT beads (can be used for single or dual color) Color rendering index: ≥ 90 Average lifespan: 50000H
Color temperature correction: 3200K~7200 K linear adjustment
Lens angle: 45 °
Luminous angle: can be manually adjusted, with electric focusing to adjust the size of the luminous area
Strobe: Independent electronic strobe 1-25Hz, random strobe, pulse strobe, synchronous step strobe, monochrome, mixed color temperature strobe
Color mixing: W, Y linear color mixing, adjustable saturation from 0 to 100%
Electronic dimming: 0-100% independent electronic linear dimming, real and flickerless camera video, automatic synchronization function between master and slave, normal control of the control console, permanent synchronization of self walking
Nixie tube display menu: call various scenes, and the built-in program can be directly called for execution
Control modes: multiple voice control, DMX512, built-in program self running, master-slave online mode
Channel: 3, 4 channels (two channel modes are optional)
Lamp connection: three core signal wire IN/OUT power wire IN/OUT
Features: Cast aluminum casing, high light efficiency, uniform light mixing, stable performance, equipped with a 1 meter long power and signal cable, 1024 level ultra high gray level dimming for softer lighting,
Protection level: Electrical level II, fire resistance V-1, protection Ip20
Voice control sensitivity: 65-130dB
Working environment: -20 ℃~40 ℃
Adopting imported LED with high color rendering index as the luminous element, it meets the requirements of professional photography and photography.
LED light source is a solid-state light emitting device with a lifespan of up to 50000 hours, making it a new generation of green and environmentally friendly light source.
The high power density LED module and efficient aspherical focusing system provide high lighting efficiency, large beam angle, and uniform spot, saving 90% energy compared to traditional lamps.
Built in DMX512 signal control, brightness adjustment range 0-100%, manual adjustment with buttons, and brightness adjustment with dimming table, without the need for a silicon box.
